• 播放视频 Application Circuit of Low Noise Op-Amp TC75S67TU for Pulse Sensor

  Application Circuit of Low Noise Op-Amp TC75S67TU for Pulse Sensor

  Using a pulse sensor, which is increasingly integrated into healthcare and wearable devices, as an example, this amplifies minute detection signals and visualizes them through Arduino control + PC display.

  4:14

• 播放视频 LDO Regulator TCR15AGADJ Application & Circuit

  LDO Regulator TCR15AGADJ Application & Circuit

  Stable operation even at low input voltage via VBIAS terminal. This reference design features low dropout, high PSRR, and excellent load transient response, making it suitable for low-voltage, high-current power supplies in mobile devices.

  3:26

• 播放视频 Photovoltaic-Output Photocoupler and MOSFET as Replacement for Mechanical Relay

  Photovoltaic-Output Photocoupler and MOSFET as Replacement for Mechanical Relay

  We introduce a method to achieve long life and high reliability by replacing mechanical relays, which have been used in electrical circuits of various equipment, with semiconductor relays.

  3:34

• 播放视频 Application Circuit of Low Noise Op-Amp TC75S67TU for Pyroelectric Infrared Sensor

  Application Circuit of Low Noise Op-Amp TC75S67TU for Pyroelectric Infrared Sensor

  Using a pyroelectric infrared human detection sensor as an example, this amplifies minute detection signals and visualizes them through Arduino control + PC display.

  4:29

• 播放视频 Application Circuits of LDO Regulator TCR5BM/8BM Series for CMOS Image Sensor

  Application Circuits of LDO Regulator TCR5BM/8BM Series for CMOS Image Sensor

  This introduces Application Circuits of LDO Regulator TCR5BM/8BM Series for CMOS Image Sensor, which are useful in camera-equipped devices such as smartphones.

  3:43

• 播放视频 Automotive CXPI Communication Application Circuit

  Automotive CXPI Communication Application Circuit

  Reference design to support introduction and evaluation of next-generation automotive communication standard CXPI

  4:01

• 播放视频 Application Circuit of Low Noise Op-amp TC75S67TU for Current Sensor

  Application Circuit of Low Noise Op-amp TC75S67TU for Current Sensor

  Using a current sensor as an example, minimal shunt voltage is amplified and visualized through Arduino control + PC display.

  3:41

• 播放视频 Application Circuit of Low Noise Op-amp TC75S67TU for Ultrasonic Distance Sensor

  Application Circuit of Low Noise Op-amp TC75S67TU for Ultrasonic Distance Sensor

  Using an integrated transmit/receive ultrasonic sensor as an example, this circuit amplifies, filters, and detects weak reflected wave signals, visualizing distance through Arduino control and PC display.

  4:02

• 播放视频 Application Circuits of LDO Regulator TCR5BM/8BM Series for RF Block

  Application Circuits of LDO Regulator TCR5BM/8BM Series for RF Block

  Applicable to power supply for RF blocks using LDO regulators in Wi-Fi-enabled mobile devices such as smartphones and wearable devices.

  4:30

• 播放视频 Application Circuits of eFuse IC TCKE805 Series

  Application Circuits of eFuse IC TCKE805 Series

  This can help with the design of power supply protection using eFuse ICs in response to increasing power demand and the growing sophistication of electronic devices in recent years.

  4:47

• 播放视频 100W LLC DC-DC Converter

  100W LLC DC-DC Converter

  This is a reference design for a 100W LLC DC-DC converter that achieves soft switching through LLC resonance.

  4:33

• 播放视频 采用TC78B043FNG的3相直流无刷电机驱动电路

  采用TC78B043FNG的3相直流无刷电机驱动电路

  支持10极电机驱动，可实现空气净化器和空调的低噪声、高效率转动控制。

  3:30
